The S3 P is our most compact and lightest gun, designed for tight area applications and where touch-ups are required. HPA Pressure technology enables high viscosity product spraying.
The S3 P is our most compact and lightest gun, designed for tight area applications and where touch-ups are required. HPA Pressure technology enables high viscosity product spraying.
Product Status:
Category:
Manufacturer:
The S3 P is our most compact and lightest gun, designed for tight area applications and where touch-ups are required. HPA Pressure technology enables high viscosity product spraying.
♦ Very fine atomization for a high-gloss finish
♦ Perfectly balanced fan for easy application
♦ Ergonomic due to a very comfortable body design
♦ EZ-Adjust air cap for easy rotation adjustment
♦ Reduced trigger effort due to its in-line air valve
♦ One of the lightest manual spray guns in its category & perfectly balanced: reducing repetitive strain injuries (RSI)
♦ Large range of projectors (air cap + nozzle + needle) & stainless-steel fluid passages (compatible with a large range of solvent and water-based materials) allowing it to be used for all kinds of applications
♦ Designed from high-end materials (stainless steel, anodized forged aluminum body, brass) in conjunction with Sames's machined projectors (air caps + nozzle + needle) ensure extended product life
♦ Reduction in the number of components makes for easy and quick maintenance
| Designation | Value |
|---|---|
| Maximum Air Pressure (bar) | 6 |
| Maximum Air Pressure (psi) | 87 |
| Recommended Air Pressure (min) (bar) | 3 |
| Recommended Air Pressure (min) (psi) | 43.5 |
| Maximum Material Pressure (bar) | 6 |
| Maximum Material Pressure (psi) | 87 |
| Air Consumption (cfm) | 5.9 |
| Air Consumption (m3/h) | 10 |
| Weight (g) | 387 |
| Weight (oz) | 13.7 |
| Type of electrostatic charge | No electrostatic |
| Air Inlet Fitting | M 1/4" NPS |
| Material Inlet Port | M 1/4" NPS |
| Wetted Parts | Stainless steel 303 |
| Material pH rate | 5 - 8 |
| Spraying type | Airspray |
| Designation | Part number |
|---|---|
| S3 PRESS 08 PX | 135150201 |
| S3 PRESS 10PX | 135150202 |
| S3 PRESS 10 PGL | 135150207 |
| S3 PRESS 12PX | 135150203 |
| Designation | Part number |
|---|---|
| AIRCAP | 132640100 |
| PROJECTOR | 031150003 |
| PROJECTOR | 031150002 |
| Aircap | 132631100 |
| PROJECTOR | 031150007 |
| PROJECTOR | 031150001 |
For pricing and availability on the Sames S3 P HPA Manual Airspray Pressure Gun, call FTS at (248) 348-6700 or request a quote online.
