Maximum Fluid Pressure |
6 |
bar (psi) |
Maximum Fluid Outlet |
750 (26.3) |
cc/min (oz/min) |
Minimum Fluid Outlet |
200 (7) |
cc/min (oz/min) |
Maximum Air Pressure |
6 (87) |
bar (psi) |
Maximum Fluid Temperature |
50 (122) |
°C (°F) |
Air Inlet |
M 1/4" NPS |
|
Fluid Inlet |
M 3/8" NPS |
|
Ph |
5-8 |
|
Tips / Nozzle |
♦ |
|
Recommended CONV Air Pressure |
2.5 (36) – 3.5 (51) |
bar (psi) |
Recommended HVLP/LVLP Air Pressure |
1,5 (22) – 2,5 (36) |
bar (psi) |
Air Consumption CONV (at 2.5 - 3.5 bar / at 36 - 51 psi) |
21.8 (12.8) – 28.2 (16.6) |
m3/h (cfm) |
Transfer Efficiency CONV |
66 |
% |
Wetted Parts: Stainless Steel, POM C, Polypropylene |
♦ |
|
Air Consumption HVLP/LVLP (at 1.5 - 2.5 bar / at 22 - 36 psi) |
16.1 – 23.5 (9.5- 13.8) |
m3/h (cfm) |
Weight |
480 (16.9) |
g (oz) |
