Graco 235534 Twistork Drum Agitator, Reversible, Non-Siphon, 304 SST

Manufacturer Part Number: 235534

Twistork Drum Agitator, reversible, non-siphon, air driven, 1-1/2 HP, 37.25 in (95 cm) in length, 304 stainless steel material. Part # 235534.

(248) 348-6700

Save

Product Status:

Available

Category:

Graco Agitators

Manufacturer:

Graco

Graco 235534 Twistork Drum Agitator, Reversible, Non-Siphon, 304 SST

Description:

Twistork Drum Agitator, reversible, non-siphon, air driven, 1-1/2 HP, 37.25 in (95 cm) in length, 304 stainless steel material

Helix blade effectively mixes higher viscosity materials
Mounts directly to 2-inch drum bung
Comes in stainless steel or carbon steel
Siphon model allows material transfer though agitator shaft
Sealed agitator drive prevents material contamination and evaporation
Approved by ATEX for use in hazardous locations
Maximum viscosity is 10,000 cps

Graco part number 235534 for use with 55 Gallon (208 Liter) Drum. Call Fluid Transfer Systems at (248) 348-6700 for pricing, availability and help matching the right agitator to your finishing material.

Features:

Technical Specifications

Part Number	235534
Air Inlet Size (in)	1/8
Air Inlet Thread Type	NPT
For Use With	55 Gallon (208 Liter) Drum
Maximum Speed (RPM)	800
Maximum Viscosity (cP)	10000
Maximum Working Pressure (psi)	100
Model	Twistork
Motor Type	Pneumatic - Rotary Vane
Power Rating (HP)	1.5
Type	Agitator
Weight (lb)	17.6
Wetted Material	Stainless Steel, Fluoroelastomer, Acetal
