10:1 Merkur AA Package, 1.2 gpm (4.5 lpm) fluid flow, Wall Mount, PerformAA 15 Gun, Pump Air Controls, Gun Air/Fluid Hose, Suction Hose. Part # G10W05.
10:1 Merkur AA Package, 1.2 gpm (4.5 lpm) fluid flow, Wall Mount, PerformAA 15 Gun, Pump Air Controls, Gun Air/Fluid Hose, Suction Hose. Part # G10W05.
Product Status:
Category:
Manufacturer:
Designed to improve productivity, reduce costs, lower emissions and provide consistent, high quality finishes for all of your demanding applications.
Graco part number G10W05. Call Fluid Transfer Systems at (248) 348-6700 for pricing, availability and configuration help.
Part of the Graco Merkur Spray Packages line under Graco Spray Packages. Manufacturer page: G10W05 on Graco.
| Part Number | G10W05 |
|---|---|
| Convertible | Non-Convertible |
| Fluid Inlet Size (in) | 3/4 |
| Fluid Inlet Thread Type | NPT |
| Fluid Outlet Size (in) | 3/8 |
| Fluid Outlet Thread Type | NPT |
| Gun Included | 1 |
| Gun Model | PerformAA 15 Air Assist |
| Gun Technology | Air-Assisted |
| Gun Type | Air-Assisted |
| Hose Inlet Diameter (in) | 0.1875 |
| Includes | Pump and Gun Air Controls, Gun Hose, Suction Hose |
| Maximum Flow Rate (GPM) | 1.2 |
| Maximum Hose Length (ft) | 25 |
| Maximum Working Pressure (MPa) | 6.9 |
| Maximum Working Pressure (psi) | 1000 |
| Model | Merkur |
| Motor Type | Pneumatic |
| Mount Type | Wall Mount |
| Number of Guns | 1 |
| Power Source | Air |
| Pressure Type | High Pressure |
| Product Type | Spray Package |
| Pump Ratio | 10:1 |
| Pump Type | Pneumatic Piston Pump |
| Spray Type | Air-Assisted |
| Technology Type | Air-Assisted |
| Type | Air-Assisted Airless Sprayer |
| Weight (lb) | 48 |
| Wetted Material | Stainless Steel, Tungsten Carbide with 6% Nickel, UHMWPE, PTFE, Nylon, Engineered Plastic, Fluoroelastomer |
| Maximum Hose Length (m) | 7.6 |
Specifications as published by Graco for part G10W05.
